Leighton
 Post subject: ball joints and studs
PostPosted: Sun May 03, 2009 3:52 am
Offline
998cc
998cc
User avatar

Joined: Fri Feb 29, 2008 4:33 pm
Posts: 1039
Location: wollongong
whats the best way to seperate the ball joint hub (behind the drum) from the wheel stud holder (insert real name here.......................)

im stuck...

cheers

leighton

_________________
1975 Leyland Mini: 1060cc - resto/ ex-hsc project.
Top
 Profile

drmini in aust
 Post subject:
PostPosted: Sun May 03, 2009 10:17 am
Offline
religious status
religious status
User avatar

Joined: Fri Mar 19, 2004 6:19 pm
Posts: 39755
Location: near Baulkham Hills, NSW
I screw a slide hammer onto 1 wheel stud. :wink:

_________________
DrMini- 1970 wasaMatic 1360, Mk1S crank, 86.6HP (ATW) =~125 @ crank, 45 Dellorto (38 chokes), RE282 sprint cam, 1.5 rockers, 11.0:1 C/R. :mrgreen:
Top
 Profile

Leighton
 Post subject:
PostPosted: Sun May 03, 2009 1:26 pm
Offline
998cc
998cc
User avatar

Joined: Fri Feb 29, 2008 4:33 pm
Posts: 1039
Location: wollongong
do i have to remove the wheel bearings and seals first?

_________________
1975 Leyland Mini: 1060cc - resto/ ex-hsc project.
Top
 Profile

drmini in aust
 Post subject:
PostPosted: Sun May 03, 2009 1:39 pm
Offline
religious status
religious status
User avatar

Joined: Fri Mar 19, 2004 6:19 pm
Posts: 39755
Location: near Baulkham Hills, NSW
Take off the hub nut and brake drum, then the drive flange (with studs) pulls out of the swivel hub (with balljoints) with slide hammer.
Sometimes the outer bearing comes too, and you have to grind or pull it off the drive flange afterwards.

_________________
DrMini- 1970 wasaMatic 1360, Mk1S crank, 86.6HP (ATW) =~125 @ crank, 45 Dellorto (38 chokes), RE282 sprint cam, 1.5 rockers, 11.0:1 C/R. :mrgreen:
Top
 Profile

gafmo
 Post subject:
PostPosted: Sun May 03, 2009 1:43 pm
Offline
the King of Bling
User avatar

Joined: Thu Jun 03, 2004 11:11 pm
Posts: 19858
Location: Baulkham Hills
If you have a old Drum sitting around put on backwards with wheel nuts with around 4 threads and try and slide it out as per Doc's method

_________________
Stop Licking the Dog...I Don't Care Who Started It
Top
 Profile

850man
 Post subject:
PostPosted: Sun May 03, 2009 1:46 pm
Offline
1098cc
1098cc

Joined: Tue Jun 12, 2007 2:07 pm
Posts: 1882
Location: Lemmings, everywhere.
I gather you are talking about the drive flange? After removing the CV joint, tap the drive flange out from behind with a appropriately sized drift. I made mine out of bar stock in a lathe, it end is machined down to fit inside the drive flange where the CV usually is. The inner race of the wheel bearing often gets suck on the flange shaft and all the balls fall out, so be prepared to replace the wheel bearings if required.

_________________
Have a Nice Day.
If already having a nice day please disregard.
Top
 Profile

drmini in aust
 Post subject:
PostPosted: Sun May 03, 2009 1:53 pm
Offline
religious status
religious status
User avatar

Joined: Fri Mar 19, 2004 6:19 pm
Posts: 39755
Location: near Baulkham Hills, NSW
Be careful bashing it out this way, is fine with a fitted mandrel like that but if you use a BFH and just any old drift, you will stuff the end of the drive flange....

_________________
DrMini- 1970 wasaMatic 1360, Mk1S crank, 86.6HP (ATW) =~125 @ crank, 45 Dellorto (38 chokes), RE282 sprint cam, 1.5 rockers, 11.0:1 C/R. :mrgreen:
Top
 Profile

Leighton
 Post subject:
PostPosted: Sun May 03, 2009 2:10 pm
Offline
998cc
998cc
User avatar

Joined: Fri Feb 29, 2008 4:33 pm
Posts: 1039
Location: wollongong
ive got the drive flange down to about halfway inside the hub now there looks to be a spacer or what i assume to be a spacer, stopping any downward movement. what now?

is the hole spline and bearing assembly tapered?


thanks for the tips.

_________________
1975 Leyland Mini: 1060cc - resto/ ex-hsc project.
Top
 Profile

drmini in aust
 Post subject:
PostPosted: Sun May 03, 2009 4:08 pm
Offline
religious status
religious status
User avatar

Joined: Fri Mar 19, 2004 6:19 pm
Posts: 39755
Location: near Baulkham Hills, NSW
Nope all parallel, it should knock right out.

_________________
DrMini- 1970 wasaMatic 1360, Mk1S crank, 86.6HP (ATW) =~125 @ crank, 45 Dellorto (38 chokes), RE282 sprint cam, 1.5 rockers, 11.0:1 C/R. :mrgreen:
Top
 Profile
